Eaton HCLR3 Class Cc Fast Acting Fuse 3A 600V 200kaic

Product Description

The EATON HCLR3 is a Class CC fast-acting fuse rated at 3 amps and 600 volts, designed for overcurrent protection in branch circuit and control circuit applications. Built to a 200 kAIC interrupting rating, it provides high fault-current capacity in a compact form factor. This non-indicating fuse follows the standard Class CC ferrule format and is sold in a pack of 10. Electricians and industrial maintenance technicians install these fuses in fusible disconnect switches, control panels, and motor control centers where space-saving Class CC fuse blocks are specified.

The HCLR3 suits residential, commercial, and light industrial electrical installations where Class CC fuse holders are present. Its fast-acting response characteristic makes it appropriate for protecting semiconductors, transformers, and control circuits that require quick response to overloads and short circuits. The 600-volt rating covers standard single-phase and three-phase distribution voltages found in North American electrical systems. This fuse type is commonly specified by electricians following NEC requirements for branch circuit and supplementary protection.

Key Features

• 3 amp continuous current rating for precise overcurrent protection
• 600 volt AC rating covers standard single-phase and three-phase circuits
• 200 kAIC interrupting rating provides high fault-current protection
• Fast-acting response suits semiconductor and control circuit protection
• Non-indicating design in standard Class CC ferrule form factor
• Sold as a pack of 10 fuses for jobsite stocking

Compatibility

Designed as a direct-fit replacement for standard Class CC fuse holders and fusible disconnect switches rated for Class CC ferrule fuses.

Installation Notes

Class CC fuses are installed by licensed electricians in accordance with NEC requirements for the applicable circuit type. Always de-energize and lock out the panel or disconnect before replacing fuses. Use an insulated fuse puller rated for the circuit voltage when removing or installing fuses in energized-adjacent equipment. Verify the replacement fuse amp rating matches the circuit design before restoring power.

Technical Specifications

• Amperage: 3 amps
• Voltage Rating: 600 volts
• Fuse Class: Class CC
• Interrupting Rating: 200 kAIC
• Response Type: Fast acting
• Indicating: Non-indicating
• Quantity per Pack: 10
• UPC: 782634420620

Standard Information

• Brand: EATON
• Manufacturer Part Number: HCLR3
