Eaton H28008-250R Hydraulic Hose 3500 Psi 0.5 in Id

Product Description

The EATON H28008-250R is a single-wire braid hydraulic hose rated for 3,500 psi working pressure. It measures 0.5 inches inner diameter and 0.875 inches outer diameter, with a 7-inch minimum bend radius. The outer cover is black neoprene, which resists oil, abrasion, and weather exposure. This hose is sold and priced in 1-foot increments from a 250-foot coil, with a minimum cut length of 20 feet. Hydraulic technicians and fluid power mechanics install this hose in medium-pressure hydraulic circuits on mobile and industrial equipment.

This hose is suited for medium-pressure hydraulic return and pressure lines in applications where flexible routing is required. The neoprene cover handles temperatures from -40 degrees F to 212 degrees F, making it appropriate for both cold-climate outdoor equipment and moderate-heat industrial environments. Typical installations include agricultural machinery, construction equipment, and industrial hydraulic power units where a 0.5-inch bore line is specified. The 250-foot coil format supports shop fabrication and field cut-to-length applications.

Key Features

• 3,500 psi rated working pressure for medium-pressure hydraulic circuits
• 0.5 inch ID with 0.875 inch OD for standard medium-bore hydraulic line routing
• Neoprene outer cover resists oil, abrasion, and weathering
• 7-inch minimum bend radius allows flexible routing in tight equipment installations
• Rated from -40 degrees F to 212 degrees F for broad temperature range service
• Sold in 1-foot increments from a 250-foot coil with a 20-foot minimum cut length

Compatibility

Designed as an OEM-style replacement or fabrication hose for medium-pressure hydraulic systems requiring a 0.5-inch ID hose rated at 3,500 psi working pressure.

Installation Notes

Installation should be performed by a qualified hydraulic technician or fluid power mechanic. Depressurize and lock out the hydraulic system completely before cutting, routing, or connecting this hose. Use proper hydraulic hose cutters to ensure a clean, square end before fitting installation. Do not exceed the 7-inch minimum bend radius during routing, as overbending can damage the reinforcement layer and reduce service life.
