Eaton H24312 Ptfe Hydraulic Hose 4000 Psi 3/4 Inch Id

Product Description

The EATON H24312 is a PTFE-lined hydraulic hose designed for high-pressure fluid transfer in demanding industrial and mobile hydraulic systems. Built from polytetrafluoroethylene (PTFE) with a black outer cover, this hose handles working pressures up to 4,000 psi and operates across a wide temperature range of -65 degrees F to 450 degrees F. With a 3/4 inch inner diameter and a 57/64 inch outer diameter, it delivers reliable flow capacity while maintaining a compact profile. Licensed hydraulic technicians and industrial maintenance professionals install this hose in systems where chemical resistance and broad thermal tolerance are required.

The H24312 is suited for industrial hydraulic circuits, mobile equipment, and fluid transfer lines where conventional rubber hose is inadequate due to chemical compatibility or temperature extremes. The PTFE construction resists most aggressive hydraulic fluids, fuels, and solvents. This hose ships as a 50-foot coil priced in 1-foot increments with a 5-foot minimum cut length. It is appropriate for both original-equipment assembly and field replacement in industrial and mobile hydraulic applications.

Key Features

• PTFE (polytetrafluoroethylene) liner provides excellent chemical and fluid compatibility
• 4,000 psi maximum working pressure for high-pressure hydraulic circuits
• Wide service temperature range: -65 degrees F to 450 degrees F
• 9-inch minimum bend radius supports routing in confined equipment spaces
• FDA approved materials per supplier specifications
• Sold in 1-foot increments from a 50-foot coil; 5-foot minimum cut length

Compatibility

Designed as a replacement or original-equipment hose for high-pressure hydraulic systems requiring PTFE construction and 4,000 psi working pressure capability. Part of the EATON H243 series.

Installation Notes

Installation should be performed by a qualified hydraulic technician or industrial mechanic. Depressurize and bleed the hydraulic system completely before cutting, connecting, or removing any hose assembly. Ensure all fittings are rated for the hose working pressure and are compatible with PTFE-lined hose ends. Verify the installed bend radius does not fall below 9 inches to avoid liner deformation or premature hose failure.
