Eaton H2005B-3 Freedom Definite Purpose Heater Coil Pack, 32/75 A, 3 Poles

Product Description

Eaton H2005B-3 is designed for use as a heater coil in industrial settings. This Freedom series component works effectively with overload relays rated for 32 or 75 amps. The heater coil is compatible with various NEMA sizes and provides reliable operation even in demanding environments. The current range is between 1.20 to 1.96 amps. It accommodates standard trip Class 20 protections.

• Usage: Ideal for NEMA and IEC Freedom Series.
• Features dial positions A, B, C, and D.
• Two reset options: manual or automatic.

Product Highlights

This heater coil works with starter sizes 00-0, sizes 1-2, and 5-8. It is suitable for industrial heating processes and temperature regulation across manufacturing facilities.

Product Information

Standard Information

• Manufacturer: Eaton
• Type: Definite Purpose

Technical Specifications

• Amperage Rating: 32/75 A
• Full Load Current: 1.2/1.45/1.71/1.96 A
• Number of Poles: 3
• Trip Type: Class 20/Standard Trip
• Enclosure Type: NEMA 00/0/1/2/5/8
• UPC: 782113967516
• GTIN: 00782113967516
• Country of Origin: Dominican Republic
