Eaton GUB03 Crouse-Hinds series Junction Box 11 inches x 12 inches x 8-13/16 inches

Product Description

The Eaton GUB03 Crouse-Hinds series junction box is designed for use in threaded rigid conduit systems within hazardous areas. Functioning as a splice box, pull box, or equipment enclosure, it houses wiring indoors and outdoors. Features a 9-5/8" cover opening and measures 11" x 12" x 8-13/16".

• Threaded construction for use in hazardous areas
• Thick walls suitable for factory or field drilling and tapping
• Neoprene O-ring gasket on covers for a watertight seal

Product Highlights

Explosionproof, dust ignitionproof, and raintight, the GUB series junction box is ideal for hazardous locations.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: GUB03
• Country of Origin: United States

Technical Specifications

• Catalog Number: GUB03
• Manufacturer: Eaton Crouse-Hinds
• Brand: Eaton
• Sub Brand: Crouse-Hinds series
• Country of Origin: United States
• Made in USA: Yes
• Application: Ind Facilities & Factories - Facility: Power Distribution and Control
• UPC: 782274469904
• GTIN: 00782274469904
• Item Type: Junction box
• Finish: Aluminum Acrylic Painted/Electro-Galvanized
• Material: Feraloy Iron Alloy
• Series: GUB
• Size: 11 in x 12 in x 8-13/16 in
• Standards/Approvals: UL 1203|CSA C22.2 No. 30|NEC Certified|CEC Class I, Division 1/2, Group C/D, Class II, Division 1, Group E/F/G, Class II, Division 2, Group F/G, Class III
• Suitable For Use With: Threaded Rigid Conduit
• Product Length/Depth: 11 in
• Product Height: 12 in
• Product Width: 8.81 in
• Product Weight: 95.04 lb
• Product Type: Junction box
• Area classification: Hazardous/Classified Locations
• Standards type: NEC/CEC
• NEC hazardous rating: Class I, Division 1 Class I, Division 2 Class II, Division 1 Class II, Division 2 Class III
• NEMA Rating: 4 7 9
• Enclosure size: 11" x 12" x 8-13/16"
• Cover opening size: 9-5/8 in
• Ingress protection (IP) ratings: IP66
• Special features: ATEX certified
