Eaton GMT-1/2A Telecommunication Fuse 0.5 A (0.81 in L x 0.688 in H) GMT12A

Product Description

Eaton GMT-1/2A is a Bussmann GMT series telecommunication fuse rated 0.50 A with voltage ratings of 125 Vac and 60 Vdc. It is a fast-acting, non-indicating fuse with a thermoplastic flat body and tin-plated beryllium copper terminals. The part provides high interrupting capacity (300 A at 125 Vac; 450 A at 60 Vdc) and uses snap-in mounting and quick-connect terminals for telecommunications and datacom circuit protection.

• Rated 0.50 A; voltage ratings 125 Vac and 60 Vdc; interrupt rating 300 AIC at 125 Vac and 450 AIC at 60 Vdc
• Fast-acting (quick blow) and non-indicating construction with tin-plated beryllium copper terminals and thermoplastic flat body
• Snap-in mounting and quick-connect terminal type; body size approximately 0.81 in L x 0.688 in H; CE, RoHS, and UL referenced certifications

Product Highlights

0.50 A telecommunication fuse; fast-acting, non-indicating; 125 Vac / 60 Vdc; 300 AIC / 450 AIC interrupt rating; tin-plated beryllium copper terminals; snap-in quick-connect mounting.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: GMT-1/2A

Technical Specifications

• Brand: EATON
• Manufacturer Part Number: GMT-1/2A
• Series: Bussmann GMT
• Product Type: Telecommunication fuse
• Amperage Rating: 0.50 A
• Voltage Rating (AC): 125 Vac
• Voltage Rating (DC): 60 Vdc
• Interrupting Rating: 300 AIC at 125 Vac; 450 AIC at 60 Vdc
• Blow Characteristic: Fast-acting
• Indication: Non-indicating
• Terminal Material/Plating: Tin-plated beryllium copper
• Terminal Type: Quick-connect
• Mounting Type: Snap-in
• Body Material: Thermoplastic
• Body Size: 0.81 in L x 0.688 in H
• Certifications: CE; RoHS; UL (Guide JFHR2/E56412); UL 94-V-0 Flammability Rating
• Replacement MPN: GMT12A
