Eaton GHC3025 Series C Molded Case Circuit Breaker 25A

Product Description

The Eaton GHC3025 is a Series C complete molded case circuit breaker. This three-pole, 25A breaker is designed with fixed thermal and fixed magnetic trip type. It is suitable for use at 480Y/277 Vac and 125/250 Vdc, with interrupt ratings of 65 kAIC at 240 Vac and 14 kAIC at 480Y/277 Vac. Operates at 50/60 Hz.

• Fixed thermal, fixed magnetic trip type
• Interrupt rating: 14 kAIC at 480Y/277 Vac, 65 kAIC at 240 Vac
• Suitable for Eaton Series C Enclosures, OEM Panels, DIN Rail (with adapter)

Product Highlights

The Eaton GHC3025 circuit breaker provides thermal-magnetic protection for commercial facilities. It integrates into Eaton enclosures and OEM panels.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: GHC3025

Technical Specifications

• SKU: GHC3025
• Product Name: Eaton Series C complete molded case circuit breaker
• Catalog Number: GHC3025
• UPC: 786679174210
• Product Length/Depth: 2.63 in
• Product Height: 4.88 in
• Product Width: 3 in
• Certifications: UL Listed
• Product Type: Molded case circuit breaker
• Amperage Rating: 25 A
• Voltage rating: 480Y/277 Vac, 125/250 Vdc
• Trip Type: T186
• Circuit breaker type: GHC
• Circuit breaker frame type: Complete breaker
• Series: Series C
• Frame: G
• Frequency rating: 50/60 Hz
• Interrupt rating: 14 kAIC at 480Y/277 Vac 65 kAIC at 240 Vac
• Number of poles: Three-pole
• Brand: Eaton / Cutler-Hammer
• Part Number: GHC3025
• Amperage: 25A
• Voltage: 240VAC, 480Y/277VAC, 125/250VDC
• Poles: 3
• Phase: 3
• AIC Rating: 65kA @ 240VAC, 14kA @ 480Y/277VAC, 14kA @ 125/250VDC
• Mounting Style: Unit Mount
• Terminal Type: Lugs
• For Use With: Eaton Series C Enclosures, OEM Panels, DIN Rail (with adapter)
• Trip Technology: Thermal Magnetic
• Trip Function Code: LI
• Trip Function: Long-Time, Instantaneous
• Trip Adjustability: Fixed Thermal, Fixed Magnetic
• Wire Gauge: 14-1/0 AWG
• Max Wire: 1/0 AWG
• Min Wire: 14 AWG
• Available Options: Padlock Attachment, DIN Rail Adapter
• Accessories: Line and Load Lugs Included
• Standards: CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489
• Approval: CSA, UL
• Temp Rating: 40C
• Construction Features: HACR Rated, Reverse Feed
• Manufacturer: Cutler-Hammer / Westinghouse
• Mounting: Surface
• Current Rating: 25 A
• Type: Thermal/Magnetic
• Alternate Mfr Part Number: GHC3025
• UNSPSC Code: 39120000
