Eaton GHC1030 Series C Molded Case Circuit Breaker 30A

Product Description

The Eaton GHC1030 Series C complete molded case circuit breaker is a G-frame, single-pole breaker with a 30A amperage rating. Designed for heavy-duty commercial use, it provides consistent thermal-magnetic protection. It is suitable for installation into OEM panelboards and switchboards.

• Designed for heavy-duty commercial use
• Provides consistent thermal-magnetic protection
• Accommodates 10-1/0 AWG wire

Product Highlights

This Eaton circuit breaker offers reliable performance and protection for commercial applications, with a focus on ease of installation and robust construction.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: GHC1030
• Country of Origin: United States

Technical Specifications

• Product Name: Eaton Series C complete molded case circuit breaker
• Catalog Number: GHC1030
• UPC: 786679173985
• Product Length/Depth: 2.63 in
• Product Height: 4.88 in
• Product Width: 1 in
• Certifications: UL Listed
• Product Type: Molded case circuit breaker
• Amperage Rating: 30 A
• Voltage rating: 277 Vac, 125 Vdc
• Trip Type: T186
• Circuit breaker type: GHC
• Circuit breaker frame type: Complete breaker
• Series: Series C
• Frame: G
• Frequency rating: 50/60 Hz
• Interrupt rating: 14 kAIC at 277 Vac
• Number of poles: Single-pole
• Brand: Eaton / Cutler-Hammer
• Amperage: 30A
• Voltage: 120VAC, 277VAC, 125VDC
• Poles: 1
• Phase: 1
• AIC Rating: 65kA @ 120VAC, 14kA @ 277VAC, 14kA @ 125VDC
• Mounting Style: Unit Mount
• Terminal Type: Lugs
• For Use With: Eaton Series C Enclosures, OEM Panels, DIN Rail (with adapter)
• Trip Technology: Thermal Magnetic
• Trip Function Code: LI
• Trip Function: Long-Time, Instantaneous
• Trip Adjustability: Fixed Thermal, Fixed Magnetic
• Wire Gauge: 10-1/0 AWG (Cu/Al)
• Max Wire: 1/0 AWG
• Min Wire: 10 AWG
• Available Options: Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, DIN Rail Adapter
• Accessories: Line and Load Lugs
• Standards: CSA C22.2 No. 5, IEC 60947-2, UL 489
• Approval: CSA, UL
• Temp Rating: 40C
• Construction Features: HACR Rated, Reverse Feed
• Item: Circuit Breaker
• Current Rating: 30 A
• Type: Thermal/Magnetic
