Product Description
The EATON GHB3090 is a molded case circuit breaker designed for a variety of applications. This breaker supports voltages of 277/480Y VAC and 125/250 VDC, making it suitable for many electrical needs. With a current rating of ninety amps and a thermal/magnetic trip mechanism, it delivers reliable protection for circuits.
- Rated for 277/480Y VAC and 125/250 VDC
- Features a fixed thermal and magnetic trip type
- Interrupt rating of fourteen/sixty-five kA
Product Highlights
This circuit breaker is suitable for use in panelboards, switchboards, and motor control centers. It's rated for fifty to sixty hertz and meets stringent electrical standards.
Product Information
Standard Information
-
Brand: EATON
-
Manufacturer Part No: GHB3090
Technical Specifications
-
Amperage Rating: 90 A
-
Voltage Rating: 277/480Y VAC/125/250 VDC
-
Frequency Rating: 50/60 Hz
-
Number of Poles: 3
-
Dimensions: 2.63 in L x 3 in W x 4 in H
-
Interrupt Rating: 14/65 kA
-
Enclosure Type: NEMA AB1-1993
-
Mounting Type: Bolted-On
