Eaton GHB3080 Circuit Breaker 80A 480Y/277 VAC 3 Poles

Product Description

Eaton GHB3080 is a molded case circuit breaker designed for reliable protection in electrical systems. This breaker has an amperage rating of 80A and works with 480Y/277 VAC and 125/250 VDC systems. It features a three-pole design and is suitable for various panelboard and motor control center applications.

• Fixed Thermal and Magnetic Trip Mechanism
• 65/14 kA Interrupting Rating
• NEMA 4 Enclosure for enhanced durability

Product Highlights

This circuit breaker series provides dependable performance and meets North American standards.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer Part Number: GHB3080

Technical Specifications

• Type: GHB
• Frame: G
• Phase: 3
• Series: C Series
• Voltage Rating: 480Y/277 VAC / 125/250 VDC
• Amperage Rating: 80 A
• Frequency Rating: 50/60 Hz
• Number of Poles: 3
• Interrupt Rating: 65/14 kA
• Connection Type: Line/Load
• Temperature Rating: 40 deg C
• Dimensions: 6.5 in L x 3.8 in W x 4 in H
• Trip Type: Fixed Thermal/Fixed Magnetic
• Enclosure Type: NEMA 4
