Eaton GHB3070 Molded Case Circuit Breaker 70A 480Y/277 VAC/125/250 VDC

Product Description

The Eaton GHB3070 is a molded case circuit breaker designed for efficient power distribution. It operates at 70 Amperes with a voltage rating of 480Y/277 VAC and 125/250 VDC. The unit features three poles and includes fixed thermal and fixed magnetic trip types that enhance reliability in various electrical applications.

• Suitable for panelboard and switchboard applications
• Meets UL standards for safety and performance
• Installs easily with bolted-on mounting

Product Highlights

The GHB3070 circuit breaker is suitable for commercial and industrial applications. It is known for its superior performance due to its patented contact design, which provides high-speed blow-open action.

Product Information

Standard Information

• Brand: Eaton
• MPN: GHB3070

Technical Specifications

• Type: GHB
• Frame: G
• Phase: 3
• Series: C Series
• Current Rating: 70A
• Voltage Rating: 480Y/277 VAC/125/250 VDC
• Interrupt Rating: 65/14 kA
• Frequency Rating: 50/60 Hz
• Number of Poles: 3
• Enclosure Type: NEMA 4
• Connection Type: Line/Load
• Wire Size: 10 to 1/0 AWG
• Dimensions: 6.6 in L x 3.8 in W x 4 in H
• Temperature Rating: 40 deg C
• Mounting Type: Bolted-On
• Country of Origin: Dominican Republic
• Standards: UL Listed, CSA Certified
