Eaton GHB3060 C Series Type GHB Molded Case Circuit Breaker 60A 480Y/277VAC 125/250VDC

Product Description

The Eaton GHB3060 is a molded case circuit breaker with a rating of sixty amps. It operates at 480Y/277 VAC and supports 125/250 VDC applications. This breaker features a G frame, suited for thermal magnetic trip types. It is a three-pole design made for reliable circuit protection in various electrical installations.

• Amperage rating of sixty amps.
• Voltage rating of 480Y/277 VAC and 125/250 VDC.
• Interrupt rating of 65/14 kA.

Product Highlights

Engineered for durability, the Eaton GHB3060 provides dependable circuit protection in panelboards, switchboards, and motor control centers.

Product Information

Standard Information

• Model Number: GHB3060
• Brand: Eaton

Technical Specifications

• Type: Molded Case Circuit Breaker
• Phase: 3
• Frequency: 50/60 Hz
• Wire Size: 10 to 1/0 AWG
• Mounting Type: Bolted-On
• Enclosure Type: NEMA 4
• Temperature Rating: 40 degrees Celsius
• Dimensions: 6.6 inches L x 3.8 inches W x 4 inches H
• Weight: 1.75 pounds
