Eaton GHB3045 G Frame Bolt-On Molded Case Circuit Breaker 45 A 480Y/277 Vac 125/250 Vdc

Product Description

The Eaton GHB3045 is a molded case circuit breaker designed for use in various electrical applications. This three-pole breaker has a current rating of forty-five amps and is suitable for both alternating and direct current systems. It is rated for use with 480Y/277 volts AC and 125/250 volts DC. The GHB3045 features fixed thermal and fixed magnetic trip types, enhancing its reliability and safety performance.

• Three-pole configuration
• Rated for 45 amps
• Suitable for 480Y/277 Vac and 125/250 Vdc

Product Highlights

The Eaton GHB3045 provides reliable protection for electrical assemblies, panels, and equipment used in commercial and industrial applications.

Product Information

Standard Information

• Manufacturer: Eaton
• Catalog Number: GHB3045

Technical Specifications

• Current Rating: 45 A
• Voltage Rating: 480Y/277 Vac, 125/250 Vdc
• Number of Poles: 3
• Interrupt Rating: 65 kAIC at 240 Vac, 14 kAIC at 480Y/277 Vac
• Frequency Rating: 50/60 Hz
• Frame Type: G
• Dimensions: 2.63 in (length) x 3 in (width) x 4 in (height)
• Weight: 1.7 lb
