Product Description
The Eaton GHB3030 is a molded case circuit breaker designed for reliable circuit protection. This unit features a 30 amp rating and is suitable for applications in panelboards, switchboards, and motor control centers. The GHB3030 operates at 480Y/277 volts AC and 125/250 volts DC.
- Three poles for effective current management.
- Fixed thermal and fixed magnetic trip types for reliable performance.
- NEMA 4 enclosure suitable for various environments.
Product Highlights
This circuit breaker is engineered for dependable branch circuit protection and has proven user acceptance for over 20 years.
Product Information
Standard Information
-
Brand: Eaton
-
Manufacturer Part Number: GHB3030
Technical Specifications
-
Amperage Rating: 30 A
-
Voltage Rating: 480Y/277 VAC, 125/250 VDC
-
Number of Poles: 3
-
Frequency Rating: 50/60 Hz
-
Interrupt Rating: 65/14 kA
-
Temperature Rating: 40 deg C
-
Dimensions: 6.6 in L x 3.8 in W x 4 in H
-
Wire Size: 10 to 1/0 AWG
-
Enclosure Type: NEMA 4
-
Mounting Type: Bolted-On
