EATON GHB3015 BREAKER CKT CASE MLD 15A 14KA 3 50/60HZ

Product Description

The Eaton GHB3015 Circuit Breaker is designed for reliable circuit protection. It operates at a voltage of 277 to 480 VAC and 125 to 250 VDC. This breaker features a non-interchangeable trip unit with a current rating of fifteen amps and interrupt capacity of fourteen kiloamperes. The three-pole breaker is suitable for applications in panelboards, switchboards, motor control centers, and busway installations.

• Voltage rating: 277/480 VAC and 125/250 VDC
• Current rating: 15 A with 14 kA interrupt capacity
• Designed for bolted-on mounting and NEMA 4 enclosure

Product Highlights

This product meets or exceeds North American standards and is available for systems up to six hundred volts AC or two hundred fifty volts DC with current ratings up to two thousand five hundred amps.

Product Information

Standard Information

• Manufacturer: Eaton
• Type: Molded Case Circuit Breaker

Technical Specifications

• Frame: G
• Phase: 3
• Trip Type: Non-Interchangeable/Thermal Magnetic
• Wire Size: 14 to 10 AWG
• Dimensions: 6.6 in L x 3.8 in W x 4 in H
• Frequency Rating: 50/60 Hz
• Country of Origin: Dominican Republic
