EATON GHB2030 C Series Type GHB Molded Case Circuit Breaker 480Y/277 VAC/125/250 VDC 30 A 65/14 kA Interrupt 2 Poles

Product Description

EATON GHB2030 is a C Series Type GHB molded case circuit breaker with an amperage rating of thirty amps and available for voltages of 480Y/277 VAC and 125/250 VDC. It features two poles, a fixed thermal and fixed magnetic trip type, and an interrupt rating of sixty-five and fourteen kA. These circuit breakers are designed for reliable circuit protection in panelboards, switchboards, and motor control centers.

• Durable NEMA 4 enclosure for outdoor and harsh environments.
• Compatible with wire sizes ranging from ten to one/zero AWG.
• Compliance with UL listing and exceeding North American standards.

Product Highlights

This breaker ensures a robust and dependable circuit protection solution.

Product Information

Standard Information

• Manufacturer: EATON
• MPN: GHB2030

Technical Specifications

• Type: GHB
• Frame: G
• Phase: 3
• Series: C Series
• Trip Type: Fixed Thermal/Fixed Magnetic/Non-Interchangeable
• Voltage Rating: 480Y/277 VAC/125/250 VDC
• Amperage Rating: 30 A
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 65/14 kA
• Number of Poles: 2
• Wire Size: 10 to 1/0 AWG
• Dimensions: 3.7 in L x 2.9 in W x 6.1 in H
• Temperature Rating: 40 deg C
• Mounting Type: Bolted-On
• Enclosure Type: NEMA 4
