Eaton GHB2025 G Frame Circuit Breaker 25A 480Y/277 Vac 125/250 Vdc

Product Description

Eaton GHB2025 is a G frame molded case circuit breaker designed for effective power distribution. It features a fixed thermal and magnetic trip mechanism. The circuit breaker can handle two poles and operates at a current rating of twenty-five amperes. It is suitable for use in systems up to 480Y/277 volts AC and 125/250 volts DC.

• Two-pole design with a fixed trip mechanism
• Current rating of twenty-five amps
• Operates in various applications including panelboards and switchboards

Product Highlights

This circuit breaker is reliable for protecting electrical circuits in residential, commercial, and industrial settings.

Product Information

Standard Information

• Manufacturer: Eaton
• Catalog Number: GHB2025

Technical Specifications

• Voltage Rating: 480Y/277 Vac, 125/250 Vdc
• Amperage Rating: 25 A
• Interrupt Rating: 65 kAIC at 240 Vac, 14 kAIC at 480Y/277 Vac
• Frame Type: G
• Frequency Rating: 50/60 Hz
• Number of Poles: 2
• Dimensions: 2.63 in L x 2 in W x 4 in H
• Country of Origin: Dominican Republic
