Eaton GHB1015 Molded Case Circuit Breaker 15A 277 VAC/125 VDC

Product Description

The Eaton GHB1015 is a molded case circuit breaker designed for applications requiring branch circuit protection. This single-pole, fixed thermal and magnetic trip circuit breaker operates at 15 Amps and supports voltage ratings of 277 VAC and 125 VDC. It offers robust features ideal for panelboards, switchboards, and motor control centers.

• 15 Amp current rating
• Voltage rating of 277 Vac / 125 Vdc
• Interrupt rating of 14 kAIC at 277 Vac

Product Highlights

Designed for reliable protection in electrical assemblies, the Eaton GHB1015 complies with North American standards. Its compact design facilitates installation in diverse applications.

Product Information

Standard Information

• Manufacturer:Eaton
• Type:Molded Case Circuit Breaker

Technical Specifications

• Amperage Rating:15 A
• Voltage Rating:277 Vac, 125 Vdc
• Frame:G
• Trip Type:Fixed Thermal, Fixed Magnetic
• Frequency Rating:50/60 Hz
• Dimensions:2.63 x 3.7 x 4 inches
• Weight:0.7 lb
