EATON Eaton GDC-315MA Bussmann small dimension fuse 315 mA (5.2 mm x 20.0 mm)
EATON Eaton GDC-315MA Bussmann small dimension fuse 315 mA (5.2 mm x 20.0 mm)

Eaton GDC-315MA Bussmann small dimension fuse 315 mA (5.2 mm x 20.0 mm)

EATON
Brand: EATON
SKU: GDC-315MA
Availability: In Stock

Ships same day if ordered by 12 pm
$14.99
$14.99
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The Eaton GDC-315MA is a Bussmann small-dimension electronic fuse (MPN GDC-315MA) rated 315 mA for overcurrent protection in electronic circuits. It is specified for 250 V operation, features ferrule end connections, and measures approximately 5.2 mm diameter by 20.0 mm length. The fuse has time-delay (slow blow) characteristics, a high interrupt rating, and is suitable for clip/holder mounting in compact assemblies.

  • Rated 315 mA, 250 V; time-delay (slow blow) characteristic
  • Compact 5.2 mm diameter x 20.0 mm length with ferrule end terminals for clip/holder mounting
  • 350 kAIC interrupt rating; certified to CSA and UL; meets IEC 60127-2 recognition

Product Highlights

Small-dimension time-delay fuse for electronic circuit protection, 315 mA at 250 V, ferrule ends, 5.2 mm x 20.0 mm, 350 kAIC.

Product Information

Standard Information

  • Brand: EATON
  • Manufacturer Part Number: GDC-315MA
Technical Specifications
Brand
Eaton
Manufacturer
Bussmann Mfg.
Manufacturer Part Number
GDC-315MA
Series
GDC (Bussmann)
Type
Small-dimension fuse (time-delay / slow-blow)
Current Rating
315 mA
Voltage Rating
250 VAC; 32 VDC
Interrupt Rating
350 kAIC
Dimensions
5.2 mm diameter x 20.0 mm length (0.205 in x 0.787 in)
Body Type
Glass cylindrical
End Type
Ferrule end x ferrule end
Terminal Type
Ferrule
Mounting Type
Clip/holder
Response Time
Time-delay (slow-blow). Multiple response-time points are listed in some datasheets.
Standards/Approvals
CSA; UL; IEC 60127-2; cULus (Guide JDYX2/JDYX8, File No. E19180); IMQ (File No. E1921)
Material
Glass body with nickel-plated brass end caps
Resistance (typical cold)
≈450 mOhm (manufacturer datasheet value)
GTIN
00051712432269
UPC
05171243226
