Eaton GDC-250MA Bussmann Series GDC-250MA Small Dimension Fuse 250mA 250V

Product Description

The Eaton GDC-250MA is a Bussmann series small dimension fuse designed for use in electronic circuits. This fuse is rated for 250 milliamps at 250 volts AC. It features a cylindrical body and is ideal for applications requiring a time delay. The fuse offers a reliable solution for protecting sensitive electronic components from overload and short circuit conditions.

• 250mA current rating
• Cylindrical body design
• Ferrule terminal type

Product Highlights

This product is suitable for electronics where circuit protection is needed. It ensures safety and functionality in various devices.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer Part Number: GDC-250MA

Technical Specifications

• Voltage Rating: 250 VAC/32 VDC
• Amperage Rating: 250 mA
• Type: Electronic Small Dimension
• Body Size: 5.2 mm diameter x 20 mm height
• Body Type: Cylindrical
• Material: Glass
• Mounting Type: Clip/Holder
• Response Time: 2 min, 200 ms, 10 s, 40 ms, 3 s, 10 ms, 300 ms
• Frequency Rating: 50 Hz
• Standards/Approvals: IEC 60127-2, cULus Guide JDYX2/JDYX8
• Element: Single
• Terminal Type: Ferrule
