Eaton GDC-1A BUS SMALL DIMENSION FUSE

Product Description

Eaton GDC-1A is a Bussmann electronic small dimension time delay fuse designed for circuits requiring precise protection. This fuse offers a rated current of one ampere and is suitable for applications involving up to two hundred fifty volts AC or thirty-two volts DC. It features a cylindrical shape and a glass body, providing robust performance in various settings.

• Rated current: 1 A
• Interrupt rating: 35 A at 250 VAC
• Glass tube with nickel-plated brass end caps

Product Highlights

This fuse is engineered for electronic circuits and delivers reliable performance with its time-delay capability. Its compact size allows for easy installation in tight spaces.

Product Information

Standard Information

• Manufacturer: Eaton
• Product Name: GDC-1A BUS SMALL DIMENSION FUSE

Technical Specifications

• Amperage Rating: 1 A
• Voltage Rating: 250 VAC/32 VDC
• Frequency Rating: 50 Hz
• Body Size: 5.2 mm Dia x 20 mm H
• Body Type: Cylindrical
• Element: Single
• Material: Glass
• Mounting Type: Clip/Holder
• Response Time: 2 min, 600 ms, 10 s, 150 ms, 3 s, 20 ms, 300 ms
• Standards/Approvals: IEC 60127-2|cULus Guide JDYX2/JDYX8, File No. E19180 Recognized|IMQ File No. E1921, CA03.00530|MITI/JET File No. JET1641-31003-1005
