Eaton GDC-1.6A Bussmann Series GDC-1.6A 1.6 Amp Small Dimension Fuse

Product Description

The Eaton GDC-1.6A is a time-delay fuse designed for electronic circuits. It has a rating of 1.6 Amps and operates at voltages up to 250 VAC or 32 VDC. This fuse is self-certified and is part of the Bussmann Series, known for reliability and safety in power distribution.

• Time-delay feature for managing overload situations
• Compact size for limited space applications
• Compliant with VDE and RoHS standards

Product Highlights

This fuse is ideal for protecting electronic circuits from overload and short circuits, ensuring optimal performance and safety.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Bussmann Mfg.

Technical Specifications

• MPN: GDC-1.6A
• Type: Time-delay fuse
• Voltage Rating: 250 VAC / 32 VDC
• Amperage Rating: 1.6 A
• Frequency Rating: 50 Hz
• Material: Fiberglass
• Body Size: 5.2 mm diameter x 20 mm height
• Interrupt Rating: 35 AIC at 250 VAC
• Applications: Electronic Circuits
• Connection Type: Ferrule End x Ferrule End
• Standards/Approvals: IEC 60127-2, cULus Guide JDYX2/JDYX8
• Rejection: Non-Rejection
