Product Description
The Eaton GDA-3.15A is a fast-acting fuse designed to protect electronic circuits effectively. It has an amperage rating of three point fifteen amperes and can handle voltages up to two hundred fifty volts AC and thirty-two volts DC. This fuse is ideal for applications requiring reliable overcurrent protection.
- Fast-acting design for quick response to overloads
- Cylindrical shape for compatibility with standard fuse holders
- High interrupt rating of one thousand five hundred amperes
Product Highlights
These fuses are suitable for use in various electronic applications, providing essential protection against faults
Product Information
Standard Information
-
Brand: Eaton
-
Manufacturer: Bussmann Mfg.
Technical Specifications
-
MPN: GDA-3.15A
-
Type: Fast-acting fuse
-
Voltage Rating: 250 VAC, 32 VDC
-
Amperage Rating: 3.15 A
-
Body Size: 5.20 mm Diameter x 20.00 mm Height
-
Material: Ceramic tube with nickel-plated brass end caps
-
Applications: Electronic circuits
-
Mounting Type: Clip/Holder
-
Response Time: 60 min, 30 min, 10 ms, 3 s, 3 ms, 300 ms, 20 ms
-
Interrupt Rating: 1.5 kAIC at 250 VAC
-
Standards/Approvals: UL Guide JDYX2, CSA File No. 53787, IEC 60127-2
