Eaton GDA-1.25A Bussmann Series GDA-1.25A 1.25 Amp Ceramic Tube Small Dimension Fast Acting Fuse

Product Description

The Eaton GDA-1.25A is a Bussmann Series fast-acting fuse rated at one point twenty-five amps. It operates at a voltage of two hundred fifty volts AC and is suitable for various applications, particularly in electronic circuits. The fuse features a cylindrical body with dimensions of five point two millimeters in diameter and twenty millimeters in height. Known for its high breaking capacity, this fuse ensures reliable performance in safety and security systems.

• Fast-acting design for quick response
• High interrupt rating of one thousand five hundred amps
• Constructed with ceramic material for durability

Product Highlights

This small dimension fuse provides reliable overcurrent protection in electrical systems. Ideal for installation in Bussmann Series holders or clips.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Bussmann Mfg.

Technical Specifications

• Amperage Rating: 1.25 A
• Voltage Rating: 250 VAC, 32 VDC
• Frequency Rating: 50 Hz
• Body Size: 5.2 mm Dia x 20 mm H
• Body Type: Cylindrical
• Material: Ceramic
• Mounting Type: Clip/Holder
• Terminal Type: Ferrule
• Response Time: 60 min, 30 min, 10 ms, 3 s, 3 ms, 300 ms, 20 ms
• Interrupt Rating: 1500 A at 250 VAC
• Applications: Safety and security systems in industrial facilities
