Product Description
The Eaton GD2020 is a 2 pole molded case circuit breaker designed for effective protection in power distribution applications. This unit features a current rating of twenty amps and supports voltages of up to 480 VAC and 125/250 VDC. The breaker is suitable for electrical assemblies, panel boards, and motor control centers.
- Two-pole, rated for twenty amps
- Interrupt ratings are sixty-five kAIC at 240 VAC and fourteen kAIC at 480 VAC
- Fixed thermal and magnetic trip types for reliable operation
Product Highlights
Ideal for use in electric assemblies and for protecting sensitive electrical equipment.
Product Information
Standard Information
-
Brand: Eaton
-
Manufacturer: Cutler-Hammer / Eaton
Technical Specifications
-
Catalog Number: GD2020
-
Current Rating: 20 Am
-
Voltage Rating: 480 VAC, 125/250 VDC
-
Trip Type: Fixed Thermal, Fixed Magnetic
-
Frame: G
-
Number of Poles: 2
-
Interrupt Rating: 65 kAIC (240 VAC), 14 kAIC (480 VAC)
-
Frequency Rating: 50/60 Hz
-
Country of Origin: Dominican Republic
-
UL Listed: Yes
