Eaton GBB-5-R BUS GBB 5A FA

Product Description

Eaton GBB-5-R is a very fast-acting fuse designed for electronic circuit protection. With a rating of five amperes, this fuse supports voltage levels up to two hundred fifty volts AC and one hundred twenty-five volts DC. The product features a cartridge body made from ceramic with a diameter of one quarter inch and a length of one and one quarter inch.

• Designed for electronic circuit applications
• Fast response time of one second at two hundred fifty percent of the ampere rating
• RoHS compliant and UL recognized

Product Highlights

The GBB-5-R fuse is essential for applications requiring immediate protection for sensitive electronics.

Product Information

Standard Information

• Manufacturer: Eaton
• UPC: 05171254994

Technical Specifications

• Amperage Rating: 5 A
• Voltage Rating: 250 VAC, 125 VDC
• Body Size: 1/4 in Dia x 1-1/4 in L
• Body Type: Cartridge
• Response Time: 1 s, 2 min
• Material: Ceramic
• Mounting Type: Clip/Holder
• Standards/Approvals: RoHS Compliant, UL Recognized to 248-14, CSA Class 1422-30, CE Certified
