Eaton GBB-10-R GBB 10A Fuse

Product Description

The Eaton GBB-10-R is a Bussmann 10 Amp very fast acting fuse designed for use in electronic circuits. This fuse meets UL 248-14 standards and is ideal for protecting sensitive electronic components. It features a ceramic body and ferrule terminal, making it suitable for clip or holder mounting.

• Very fast acting performance for sensitive electronics
• Rated for 10 A at 250 VAC and 125 VDC
• Compact size of 1/4 inch diameter by 1-1/4 inches long

Product Highlights

The fuse provides a 10 kA interrupt rating and responds within 1 second at 250% of the rated current. This product is designed with a cartridge body and is ideal for installations where space is limited.

Product Information

Standard Information

• Brand: Eaton
• UPC: 05171254988

Technical Specifications

• Amperage Rating: 10 A
• Application: Electronic Circuit Applications
• Body Size: 1/4 in Dia x 1-1/4 in L
• Body Type: Cartridge
• Indicating: Non-Indicating
• Manufacturer Part Number: GBB-10-R
• Material: Ceramic
• Mounting Type: Clip/Holder
• Response Time: 1 s, 2 min
• Series: GBB
• Standards/Approvals: RoHS Compliant, UL Recognized to 248-14, CSA Class 1422-30, CE Certified
• Terminal Type: Ferrule
• Type: Size 3AB
• Voltage Rating: 250 VAC, 125 VDC
