Eaton FWP-125A BUS HIGH SPEED FUSE 125 A 700 VAC/VDC

Product Description

The Eaton FWP-125A BUS HIGH SPEED FUSE is a high-performance fuse rated at one hundred twenty-five amps. It operates up to seven hundred volts AC or DC and features a two hundred kiloamp interrupt rating. The fuse is designed for applications demanding superior protection and isolation for electronic components like diodes and silicon controlled rectifiers.

• High-speed fuse for superior performance
• Rated for 125 A and 700 VAC/VDC
• 200 kAIC interrupt rating for enhanced reliability

Product Highlights

This fuse is ideal for industrial and factory environments, ensuring safety in DC drives and power converters.

Product Information

Standard Information

• Manufacturer: Eaton
• UPC: 05171215036

Technical Specifications

• Amperage Rating: 125 A
• Voltage Rating: 700 VAC/VDC
• Body Size: 1.5 in Dia x 5.09 in L
• Body Type: Cartridge
• Material: Fiberglass
• Terminal Type: Blade End
• Series: FWP
• Standards/Approvals: CE Certified, CSA Certified, RoHS Compliant, UL Listed, UL Recognized
