Product Description
The Eaton FWP-10A14F is a fast-acting high-speed fuse designed for electrical applications. This fuse operates at ten amps and is rated for seven hundred volts alternating current. It has a high interrupt rating of two hundred kiloamps, making it suitable for challenging environments.
- High-speed operation for effective circuit protection
- Non-indicating fuse type with a cylindrical body
- Designed for use with ferrule end terminals
Product Highlights
Ideal for protecting AC and DC drives, the Eaton FWP-10A14F is part of the Bussmann series fuses, ensuring reliability in various electrical assemblies.
Product Information
Standard Information
-
Manufacturer: Eaton
-
Manufacturer Part Number: FWP-10A14F
Technical Specifications
-
Amperage Rating: 10 A
-
Voltage Rating: 700 VAC
-
Frequency Rating: 45 to 1000 Hz
-
Body Size: 0.563 in Dia x 2 in L
-
Body Type: Cylindrical
-
Element: Single
-
Material: Ceramic
-
Mounting Type: Holder
-
Terminal Type: Ferrule End
-
Class: aR
-
Standards/Approvals: CE Marking, CSA 1422, RoHS Compliant, UL Listed
