Eaton FWH-50B BUS 500V SEMICONDUCTOR (1)

Product Description

Eaton's FWH-50B is a fast-acting high-speed fuse designed for use in electrical applications. This fuse is rated for fifty amps and operates at five hundred volts alternating current. It can interrupt up to two hundred kiloamperes, making it suitable for protective measures in power converters and electrical panels.

• Fast-acting design for immediate response to overloads
• Cylindrical ceramic body measuring point eight one three inches in diameter by three point one eight eight inches in length
• Compatible with blade end terminal and stud mounting types

Product Highlights

This fuse ensures safety and reliability in electrical assemblies and is suitable for various applications including DC drives and industrial facilities.

Product Information

Standard Information

• Manufacturer: Eaton
• Manufacturer Part Number: FWH-50B

Technical Specifications

• Amperage Rating: 50 A
• Voltage Rating: 500 VAC
• Interrupting Rating: 200 kA
• Body Type: Cylindrical
• Material: Ceramic
• Frequency Rating: 45 to 1000 Hz
• Mounting Type: Stud
• Terminal Type: Blade End
• Standards/Approvals: CE Marking, CSA Certified, UL Listed File No. E91958
