Eaton FWH-350A BUSS 500V Semiconductor Fuse (1)

Product Description

The Eaton FWH-350A is a North American style high speed fuse with an amperage rating of three hundred fifty. It operates at a voltage of one thousand volts alternating current or eight hundred volts direct current. This fuse is designed for high performance applications where reliable interruption is critical.

• Low arc voltage and energy let-through reduce damage.
• Excellent performance for direct current applications.
• Fiber reinforced body for durability.

Product Highlights

This fuse protects components in industrial and factory settings, making it ideal for DC drives, power converters, and rectifiers.

Product Information

Standard Information

• Voltage Rating: 1000 VAC/800 VDC
• Amperage Rating: 350 A

Technical Specifications

• Body Size: 1.5 inches diameter x 4.34 inches length
• Body Type: Cartridge
• Element: Single
• Material: Fiberglass
• Mounting Type: Stud
• Terminal Type: Blade End
• Series: FWH
• Indicating/Non-Indicating: Non-Indicating
• Rejection/Non-Rejection: Non-Rejection
• Standards/Approvals: CE Certified, CSA Class 1422-30 File No. 53787, RoHS Compliant, UL Recognized to Guide No. JFHR2 File No. E56412
