Eaton FWH-175B BUS 500V SEMICONDUCTOR FUSE

Product Description

The Eaton FWH-175B is a fast-acting, high-speed fuse designed for electrical protection. This fuse has an amperage rating of one hundred seventy-five amps and operates at a voltage of five hundred volts AC. It features a cylindrical ceramic body and is suitable for AC and DC applications. The fuse is ideal for use in electrical assemblies, panels, and equipment requiring reliable overcurrent protection.

• Fast-acting performance for quick response to overloads
• Suitable for AC and DC drives, power converters, and safety systems
• Designed to handle up to two hundred kilovolt-amps interrupt rating

Product Highlights

The Eaton FWH-175B fuse is engineered for high efficiency and reliability. Its design allows for minimal energy let-through, improving system safety.

Product Information

Standard Information

• Manufacturer: Eaton
• UPC: 05171279585

Technical Specifications

• Amperage Rating: 175 A
• Voltage Rating: 500 VAC
• Body Size: 1.156 in Diameter x 3.625 in Length
• Body Type: Cylindrical
• Material: Ceramic
• Mounting Type: Stud
• Indicating Type: Non-Indicating
• Frequency Rating: 45 to 1000 Hz
• Series: FWH
• Standards/Approvals: CE Marking, CSA Certified, RoHS Compliant, UL Listed
