Eaton FWA-5A10F BUSS 150V SEMICONDUCTOR FUSE (1)

Product Description

This Bussmann FWA-5A10F fast acting semi-conductor high speed fuse is designed for effective protection in electrical systems. It features a rating of five amperes and operates at one hundred fifty volts AC. This fuse is suitable for various applications including AC and DC drives, electrical assemblies, and industrial facilities. It complies with safety standards and is built for high cycling capability to ensure reliability over time.

• Rating: 5 A, 150 VAC
• Interrupt Rating: 100 kA
• Body Size: 0.406 inches Diameter x 1.5 inches Length

Product Highlights

This product is engineered to meet the demands of modern electrical systems.

Product Information

Standard Information

• Manufacturer: Eaton
• UPC: 05171279519

Technical Specifications

• Type: Fast Acting Semi-Conductor
• Class: aR
• Series: FWA
• Element: Single
• Body Size: 0.406 inches Diameter x 1.5 inches Length
• Body Type: Cylindrical
• Voltage Rating: 150 VAC
• Amperage Rating: 5 A
• Frequency Rating: 45 to 1000 Hz
• Material: Ceramic
• Mounting Type: Holder
• Terminal Type: Ferrule End
• Rejection Non Rejection: Non-Rejection
• Indicating Non Indicating: Non-Indicating
• Standards/Approvals: CE Marking, CSA Certified, RoHS Compliant, UL Listed File No. E91958
