Eaton FNQ-R-9 BUS 600V MIDGET TD FUSE

Product Description

The Eaton FNQ-R-9 is a current limiting time delay fuse designed for protection in electrical systems. This fuse is rated at nine amps and can handle up to 600 volts. It has a 200 kA interrupt rating, making it suitable for various applications. The cylindrical body type ensures a secure fit in compatible fuse holders.

• Time delay feature for control transformer compatibility
• Current limitation ensures maximum short circuit protection
• CE certified and RoHS compliant for safety

Product Highlights

The Eaton FNQ-R-9 provides exceptional performance in both industrial and commercial settings. It features a rejection design that prevents improper fuse installations.

Product Information

Standard Information

• Manufacturer: Eaton
• UPC: 05171249708

Technical Specifications

• Amperage Rating: 9 A
• Voltage Rating: 600 V
• Body Size: 13/32 in Dia x 1-1/2 in L
• Body Type: Cylindrical
• Class: CC
• Element: Dual
• Indicating/Non-Indicating: Non-Indicating
• Material: Melamine Tube
• Response Time: 12 s at 200%
• Mounting Type: Holder
• Rejection Feature: Rejection
• Standards/Approvals: CE Certified, CSA, RoHS Compliant, UL 248-4
