Eaton FNQ-R-7-1/2 Bussmann Series Time Delay Fuse 7.5 A 600V

Product Description

Eaton Bussmann Series FNQ-R-7-1/2 fuse is a time delay fuse rated at seven and a half amperes. This class CC fuse is designed for applications where inrush currents are a concern. It features a ferrule end connection on each side and is suitable for use in a wide range of industrial environments.

• Time delay for small control transformers.
• Rated at 600 volts and handles high inrush currents.
• Interrupt rating of 200 kAIC for maximum protection.

Product Highlights

This fuse is ideal for line protection and is suitable for use with isolated and in-line fuse holders.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Bussmann Mfg.

Technical Specifications

• Type: Current Limiting High Inrush Time Delay
• Class: CC
• Voltage Rating: 600 V
• Amperage Rating: 7.5 A
• Body Size: 13/32 inches diameter x 1.5 inches length
• Body Type: Cylindrical
• Response Time: 12 seconds at 200%
• Material: Melamine
• Terminal Type: Ferrule End
• Interrupt Rating: 200 kAIC
• Applications: Industrial facilities, control transformers, and fuse holders
