Eaton FNQ-R-7-1/2 Bussmann Series FNQ-R Class CC Time-Delay Fuse 7.5 A (13/32 In x 1-1/2 In)

Product Description

The Eaton FNQ-R-7-1/2 is a Bussmann series Class CC time-delay fuse rated 7.5 A and 600 V. It features a melamine tube body with ferrule end terminations, a 200 kA interrupting rating, and an approximate clearing time of 12 seconds at 200% of rated current. The fuse is suitable for line protection, small control transformers, industrial control, and branch-circuit applications.

• 7.5 A rating, Class CC time-delay design with ~12 s clearing at 200%
• 600 V voltage rating, 200 kAIC interrupting capability, melamine tube construction
• Ferrule end x ferrule end terminations, rejection-style/holder mounting for CC fuse blocks

Product Highlights

Class CC time-delay fuse, 7.5 A, 600 V, 200 kAIC, ferrule end connections

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FNQ-R-7-1/2
• Country of Origin: USA

Technical Specifications

• Brand: Eaton (Bussmann)
• Manufacturer Part Number: FNQ-R-7-1/2
• Series: FNQ-R
• Product Type: Fuse
• Fuse Class: Class CC
• Fuse Type: Time-delay, dual-element, current-limiting
• Current Rating: 7.5 A
• Voltage Rating: 600 V
• Interrupting Rating: 200 kAIC
• Response Time / Clearing Time: Approximately 12 seconds at 200% of rated current
• Terminations / Connection Type: Ferrule end x ferrule end
• Body Material: Melamine tube
• Body Size / Dimensions: 13/32 in diameter x 1-1/2 in length (0.40625 in x 1.5 in)
• Mounting Type: Holder / clip mount (rejection-type for CC fuse blocks)
• Indication: Non-indicating
• Special Features: Rejection-style (prevents incorrect installation); time-delay for high inrush currents
• Applications: Line protection, small control transformers, industrial control, branch circuits, isolated and in-line fuse holders
• Standards / Certifications: UL 248-4; CE; CSA
• Material of End Caps: Nickel-plated brass
