Eaton FNQ-R-5-6/10 BUS Class CC Time-Delay Fuse 600V

Product Description

The Eaton FNQ-R-5-6/10 is a Bussmann CC-Tron® fuse designed for current limiting and time delay applications. This fuse operates at five point six amperes and is rated for six hundred volts. It has a two hundred kAIC interrupt rating, making it suitable for various industrial and safety applications.

• Time delay compatible with inrush characteristics of small control transformers.
• Current limitation at class CC levels provides protection against short circuits.
• Nickel-plated brass end caps ensure durability.

Product Highlights

This fuse features a cylindrical body type, dual element design, and a ferrule end terminal, offering reliable circuit protection. It is ideal for use in industrial facilities, safety systems, and isolated fuse holder applications.

Product Information

Standard Information

• Manufacturer: Eaton
• UPC: 05171258243

Technical Specifications

• Amperage Rating: 5.6 A
• Voltage Rating: 600 V
• Body Size: 13/32 in Dia x 1-1/2 in L
• Class: CC
• Material: Melamine Tube
• Body Type: Cylindrical
• Response Time: 12 s at 200%
• Rejection Type: Rejection
