Eaton FNQ-R-2-8/10 BUS FUSE 600V MIDGET TD

Product Description

Eaton FNQ-R-2-8/10 is a time delay fuse designed for line protection. This Bussmann CC-Tron fuse operates at two point eight amperes and is rated for six hundred volts. It features a cylindrical body and a current interrupt rating of two hundred kiloamperes. This fuse is ideal for small control transformers and various other industrial applications.

• Time delay compatible with small control transformers
• Class CC rejection prevents using lesser-rated fuses
• High interrupt rating for safety in control circuit locations

Product Highlights

The FNQ-R-2-8/10 fuse is built with nickel-plated brass end caps and has a dual element structure. This design helps provide enhanced performance in demanding conditions.

Product Information

Standard Information

• Manufacturer: Eaton
• Manufacturer Part Number: FNQ-R-2-8/10

Technical Specifications

• Amperage Rating: 2.8 A
• Voltage Rating: 600 V
• Interrupting Rating: 200 kA
• Body Size: 13/32 in Dia x 1-1/2 in L
• Body Type: Cylindrical
• Element: Dual
• Response Time: 12 s at 200%
• Material: Melamine
• Mounting Type: Holder
• Application: Line Protection, Industrial Control
• Standards/Approvals: CE Certified, RoHS Compliant
