Eaton FNQ-R-17-1/2 Bussmann Series Time Delay Fuse 4-30 Amp

Product Description

Eaton FNQ-R-17-1/2 is a time delay fuse designed for circuit protection. This Bussmann Series fuse is suitable for use in various applications including line protection and small control transformers. With a current rating of seventeen point five amps and a voltage rating up to six hundred volts, this fuse is built to perform under demanding conditions.

• Amperage rating of 17.5 A
• Response time of 12 seconds at 200%
• Interrupt rating of 200 kAIC

Product Highlights

This time delay fuse features a cylindrical body and is designed with nickel-plated brass end caps for durability. The ferrule end connection allows for easy installation into a compatible fuse holder.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Bussmann Mfg.

Technical Specifications

• Type: Current Limiting Time Delay
• Class: CC
• Voltage Rating: 600 V
• Amperage Rating: 17.5 A
• Body Size: 13/32 in Diameter x 1-1/2 in Length
• Material: Melamine Tube
• Terminal Type: Ferrule End
• Applications: Used for industrial facilities, safety systems, line protection, and control transformers
• Standards/Approvals: CE Certified, RoHS Compliant, UL Listed
