Eaton FNQ-6-1/4 Midget Fuse 6.25 A (13/32 In Diameter x 1-1/2 In Length)

Product Description

The Eaton FNQ-6-1/4 is a Bussmann series time-delay midget fuse rated 6.25 A and 500 V for protection of motor control transformers and circuits with in-rush currents. It has ferrule end-to-end connections, nickel-plated bronze endcaps, and a 10 kA interrupting rating at 500 Vac. The supplemental class cartridge measures 13/32 in diameter by 1-1/2 in length and is suitable for holder mounting, lighting, and meter circuits.

• Time-delay (dual element) midget fuse for in-rush current and motor start-up protection
• Rated 6.25 A, 500 V with 10 kAIC interrupting rating at 500 Vac
• Ferrule end x ferrule end termination and nickel-plated bronze endcaps; 13/32 in x 1-1/2 in body

Product Highlights

Time-delay midget fuse, 6.25 A, 500 V, 10 kAIC interrupting rating, ferrule end connections

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FNQ-6-1/4

Technical Specifications

• Brand: Eaton
• MPN: FNQ-6-1/4
• Series: Bussmann FNQ
• Type: Time-delay midget fuse
• Current Rating: 6.25 A
• Voltage Rating: 500 V (Vac)
• Interrupting Rating: 10 kAIC at 500 Vac
• End Type: Ferrule end x ferrule end
• Endcap Material/Finish: Nickel-plated bronze
• Body Size/Dimensions: 13/32 in (0.40625 in) diameter x 1-1/2 in (1.5 in) length
• Class: Supplemental
• Element: Dual element (time-delay)
• Mounting Type: Holder
• Applications: Motor control transformers; circuits with in-rush currents; lighting circuit protection; meter circuits
• Standards/Approvals: CSA; CE; UL 248-14
• Product Type: Midget fuse
• Indication: Non-indicating
• UPC: 051712786317
• Material: Fiberglass body with nickel-plated bronze endcaps
