Eaton FNQ-1-1/4 Bussmann Series Midget Time-Delay Fuse 1.25 A (13/32 in x 1-1/2 in)

Product Description

Eaton FNQ-1-1/4 is a Bussmann series time-delay midget fuse rated 1.25 A at 500 VAC, intended for motor control transformers and circuits with inrush currents. It is a dual-element, non-indicating supplemental fuse with ferrule end-to-end terminations, nickel-plated bronze endcaps, and a 10 kA interrupting rating at 500 VAC. Body size is 13/32 in diameter by 1-1/2 in length.

• Time-delay, dual-element design rated 1.25 A at 500 VAC for inrush current protection
• 10 kA interrupting rating; ferrule end x ferrule end termination; nickel-plated bronze endcaps
• Midget cartridge body 13/32 in dia x 1-1/2 in length; supplemental class; non-indicating

Product Highlights

Time-delay midget fuse, 1.25 A at 500 VAC, 10 kAIC, ferrule terminations

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FNQ-1-1/4

Technical Specifications

• Manufacturer Part Number: FNQ-1-1/4
• Brand: Eaton
• Series: Bussmann FNQ
• Product Type: Fuse
• Fuse Type: Time-delay (dual-element)
• Current Rating: 1.25 A
• Voltage Rating: 500 VAC
• Interrupting Rating: 10 kAIC at 500 VAC
• Class: Supplemental
• Body Type: Cartridge
• Body Size / Dimensions: 13/32 in diameter x 1-1/2 in length
• End Termination: Ferrule end x ferrule end
• Endcap Material: Nickel-plated bronze
• Material: Bronze
• Element: Dual
• Indicating: Non-indicating
• Rejection: Non-rejection
• Mounting Type: Holder
• Typical Applications: Motor control transformers; circuits with inrush currents; lighting circuit protection; meter circuits
• UPC: 051712786140
• Standards / Approvals: CE; CSA; UL; RoHS Compliant
