Eaton FNM-1/4 Midget Fuse 0.25 A (13/32 x 1-1/2 in)

Product Description

The Eaton FNM-1/4 is a Bussmann series time-delay midget fuse rated 0.25 A at 250 V. It uses dual element, non-indicating construction with ferrule end to ferrule end terminations and a melamine tube body. Interrupting capability is 10 kAIC at 125 VAC and 35 AIC at 250 VAC. Nickel-plated bronze endcaps and supplemental class construction support general purpose, lighting, meter, and inrush-tolerant circuits.

• Time-delay (dual element) midget fuse rated 0.25 A, 250 VAC
• Ferrule end x ferrule end terminations; melamine tube; size 13/32 in x 1-1/2 in
• Interrupting rating 10 kAIC @ 125 VAC and 35 AIC @ 250 VAC; nickel-plated bronze endcaps; meets UL 248-14, CSA, CE

Product Highlights

Time-delay 0.25 A midget fuse; dual element; 10 kAIC/35 AIC interrupting ratings

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FNM-1/4

Technical Specifications

• Brand: Eaton
• Manufacturer: Bussmann Mfg.
• Manufacturer Part Number: FNM-1/4
• Series: Bussmann FNM
• Type: Time-delay midget fuse
• Ampere Rating: 0.25 A
• Voltage Rating: 250 VAC
• Element: Dual (time-delay)
• Indication: Non-indicating
• Termination: Ferrule end x ferrule end
• Tube Material: Melamine
• Endcap Material: Nickel-plated bronze
• Interrupting Rating: 10 kAIC at 125 VAC; 35 AIC at 250 VAC
• Size (Diameter x Length): 13/32 in x 1-1/2 in
• Class: Supplemental
• Body Type: Cylindrical
• Mounting Type: Holder
• Rejection: Non-rejection
• Standards/Certifications: UL 248-14; CSA; CE
• Application: General purpose circuits; lighting circuit protection; meter circuits; circuits with high inrush currents
• GTIN: 00051712520072
• UPC: 05171252007
