Eaton FNA-10 Bussmann FNA Time-Delay Fuse 10 A (Dual Element)

Product Description

The Eaton FNA-10 is a Bussmann series time-delay fuse rated 10 A and 125 V designed for inductive load circuits and electronic circuits. It uses a dual-element, dual (two-element) non-indicating midget cartridge construction with ferrule end-to-ferrule end termination and silver-plated pins. The fuse provides a 10 kA interrupting rating at 125 VAC and is intended for use in compact fuseholders and holder-mounted applications.

• Dual-element time-delay construction for inrush tolerance and control circuit protection
• Rated 10 A, 125 V with 10 kA interrupting rating at 125 VAC
• Ferrule end-to-ferrule end termination with silver-plated pins; non-indicating

Product Highlights

Dual-element, time-delay 10 A fuse for inductive and electronic circuits with 10 kAIC interrupting rating and ferrule terminations.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FNA-10

Technical Specifications

• Brand: EATON
• Manufacturer Part Number: FNA-10
• Series: Bussmann FNA
• Type: Dual-element time-delay fuse (midget/cartridge)
• Application: Inductive load circuits; electronic circuits
• Current Rating: 10 A
• Voltage Rating: 125 V
• Interrupting Rating: 10 kAIC at 125 VAC
• Number of Elements: Dual
• Indication: Non-indicating
• End Termination: Ferrule end x ferrule end
• Pin Finish: Silver-plated pins
• Body Material: Fiberglass (cartridge body)
• Body Size / Dimensions: 0.40625 in diameter x 1.50 in length (0.41 in W x 0.41 in H x 1.50 in L)
• Mounting Type: Holder
• Class: Supplemental
• Standards/Approvals: CE | CSA File No. 53787 | UL File No. E19180 | RoHS Compliant
• UPC: 51712713641
