Eaton FNA-1/2 Fusetron Dual-Element 0.5 A (13/32 in x 1-1/2 in)

Product Description

The Eaton FNA-1/2 is a Bussmann series time-delay (dual-element) fuse rated 0.5 A and 250 VAC for inductive load and electronic circuits. It uses ferrule end to ferrule end terminations, a silver-plated pin, and non-indicating operation. Interrupting ratings are 35 AIC at 250 VAC and 10 kAIC at 125 VAC. The cartridge-style body measures 13/32 in diameter by 1-1/2 in length for holder mounting.

• Time-delay (dual-element) design for inductive and electronic circuits; rated current 0.5 A, voltage 250 VAC
• Interrupting rating: 35 AIC at 250 VAC; 10 kAIC (10,000 AIC) at 125 VAC
• Ferrule end x ferrule end terminations, silver-plated pin, cartridge body 13/32 in x 1-1/2 in; non-indicating

Product Highlights

Time-delay dual-element midget fuse; 35 AIC @ 250 VAC and 10 kAIC @ 125 VAC; ferrule end terminations.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FNA-1/2

Technical Specifications

• Manufacturer: Bussmann Mfg.
• Brand: Eaton
• MPN: FNA-1/2
• Catalog Number: FNA-1/2
• Type: Time-delay (dual-element) fuse
• Element: Dual (time-delay)
• Rated Current: 0.5 A
• Voltage Rating: 250 VAC
• Interrupting Rating: 35 AIC at 250 VAC; 10 kAIC at 125 VAC
• Terminations: Ferrule end x ferrule end
• Pin Finish: Silver-plated
• Body Material: Fiberglass
• Body Type: Cartridge
• Dimensions: 13/32 in diameter x 1-1/2 in length
• Mounting Type: Holder
• Class: Supplemental
• Applications: Inductive load circuits; Electronic circuits; Control circuits; Power electronic circuits with high in-rush current; Safety and security systems
• Standards/Certifications: CE, CSA, UL 248-14
• GTIN: 00051712713405
• UPC: 051712713405
• Weight: 0.0120 lb
• Series: Bussmann FNA
• Indicator: Non-indicating
