Eaton FH53 Thermal Unit, 26.50 to 28.50A

Product Description

The Eaton FH53 thermal unit replaces damaged or worn thermal units in overload relays. It is designed for use with starter size 2 and features thermal and fast trip functionality. This unit protects connected loads from overheating and causing damage.

• Used with Starter Size 2
• NEMA Design
• Thermal and fast trip

Product Highlights

The Eaton FH53 thermal unit is suitable for thermal-type overload relays and should be selected based on the appropriate operating conditions of the motor starter.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FH53
• Country of Origin: Dominican Republic

Technical Specifications

• Catalog Number: FH53
• UPC: 786678670454
• Product Length/Depth: 2.1 in
• Product Height: 0.8 in
• Product Width: 1.3 in
• Certifications: CSA Certified UL Listed
• Catalog Notes: Select heater coils based on full load current(FLA) shown on motor nameplate. Heater coils are rated to protect 40 degree C rise and a service factor of 1.15, Single-Phase requires 2 heaters, Three-Phase Requires 3 heaters
• Global Catalog: FH53
• Product Type: Heater
• Special features: Used with Starter Size 2
• Type: A200/B100 Heater
• Used with: Used with Starter Size 2
• Design: NEMA
• Full load current range: Ambient 28.8-31.4, 33.4-36.4 A, Non-Comp 26.7-29.1, 31.5-34.5 A
• Overload relay: Type A and B
• Trip type: Thermal and fast trip
• Brand: Eaton
• Series: A200/B100
• Amperage: 31.5-34.5
• Approval: UL, CSA
• Protection: Thermal
• Length (in): 2.1
• Width (in): 1.3
• Height (in): 0.8
• For Use With: Starter Sizes 0,1 and 2, Thermal Overload Relays, Magnetic Motor Starters and Motor Controls
• Standards: NEMA
• Nema Size: 2
• Mpn: FH53
• Gtin: 786678670454
• Family Series: Eaton Overload Relays
• Manufacturer: Eaton
• Manufacturer Part Number: FH53
• Approvals: CSA, UL
• Comments: Thermal and Fast Trip
• Compatible with Series: A200, B100
• Full Load Current: 28.8 to 31.4 A, 33.4 to 36.4 A
• Thermal Unit, Trip Class: 20
• Compatible with Grainger Part Number: 11Z488, 11Z489, 11Z49, 11Z491, 11Z492, 11Z493, 11Z494, 11Z495, 11Z496, 11Z497
• Compatible Manufacturer Model Number: B100J0B, B100J0C, B100J1B, B100J1C, B100M0B, B100M0C, B100M1B, B100M1C, B100S0B, B100S0C, B100S1B, B100S1C, B100U0B, B100U0C, B100U1B, B100U1C, B100W0B, B100W0C, B100W1B, B100W1C
• Full Load Current Rating: 26.5 to 28.5 A
• Size: 2.1 in L x 1.3 in W x 0.8 in H
• Overload Protection Type: Thermal
