Eaton FH50 Overload Relay Heater Type B100 #1 Size

Product Description

The EATON FH50 is an overload relay heater, identified by a catalog number stamped on one terminal. It protects 40 Deg C rise motors and open and dripproof motors having a service factor of 1.15 where the motor and the controller are at the same ambient temperature. It is used with starter sizes 1, and 2, and has a fast/thermal trip type.

• Select heater coils based on full load current (FLA) shown on motor nameplate
• Type A and b overload relay
• Heater coils are rated to protect 40 deg C rise and a service factor of 1.15

Product Highlights

The EATON FH50 overload relay heater is suitable for A200 series NEMA 1/2 starter, safety and emergency exit devices, industrial facilities and factories facility applications.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FH50

Technical Specifications

• Enclosure Type: NEMA 1/2
• Full Load Current: 0.25 to 0.27/0.29 to 0.31 A Ambient, 20.3 to 22.2/24 to 26.2 A Non-Comp
• Size: #1
• Trip Type: Fast/Thermal
• Type: Type B100
• Approval: UL, CSA
• Motor FLA: 21.8 to 27.6 Ampere
• NEMA Size: 1, 2 (Enclosed/Open)
• Used On: Type A and B Overload Relay
• Used with Starter Sizes: 1, and 2
• Standard: CSA,UL
• Height: 0.8 Inch
• Length: 2.1 Inch
• Part #: FH50
• Category: Thermal Overload/Heater
• UNSPSC: 39122330
• Application: For A200 series NEMA 1/2 starter, safety and emergency exit devices, industrial facilities and factories facility applications
• Accessory Type: Overload Heater
