Eaton FDB3015 Series C Molded Case Circuit Breaker 15A REPLACEMENT MPN

Product Description

The Eaton FDB3015 is a Series C complete molded case circuit breaker. This F-frame, three-pole breaker has a fixed thermal, fixed magnetic trip type and is rated for 15A, 600 Vac, and 250 Vdc. It is designed for load side connections and operates at 50/60 Hz. It is suitable for use with Eaton Series C panelboards and F-Frame enclosures.

• Complete breaker with fixed thermal and magnetic trip.
• Interrupting rating of 18 kAIC at 240 Vac and 14 kAIC at 480 Vac.
• Designed for commercial loads and reverse feed capable.

Product Highlights

The Eaton FDB3015 circuit breaker provides thermal-magnetic protection and is suitable for various applications, including switchboards and motor control centers.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FDB3015
• Country of Origin: United States

Technical Specifications

• Product Name: Eaton Series C complete molded case circuit breaker
• Catalog Number: FDB3015
• UPC: 786679305829
• Product Length/Depth: 3.38 in
• Product Height: 6 in
• Product Width: 4.13 in
• Certifications: UL Listed
• Product Type: Molded case circuit breaker
• Amperage Rating: 15 A
• Voltage rating: 600 Vac, 250 Vdc
• Trip Type: T186
• Circuit breaker type: FDB
• Circuit breaker frame type: Complete breaker
• Series: Series C
• Terminals: Load side
• Frame: F
• Frequency rating: 50/60 Hz
• Interrupt rating: 18 kAIC at 240 Vac 14 kAIC at 480 Vac
• Number of poles: Three-pole
• Mount: Panel mount
• Amperage: 15 Ampere
• Poles: 3 Pole
• Rating: 14k rated @ 480VAC
• Voltage: 600 VAC
• Type: Thermal magnetic
• Trip: Fixed Trip
• Approval: UL, CSA. CE
• Mfg Status: Available
• Application: Industrial
• Part Number: FDB3015
• Phase: 3
• AIC Rating: 18kA @ 240VAC, 14kA @ 480VAC, 14kA @ 600VAC, 10kA @ 250VDC
• Mounting Style: Bolt-On
• Terminal Type: Lugs
• For Use With: Eaton Series C Panelboards, F-Frame Enclosures, Switchboards, Motor Control Centers
• Trip Technology: Thermal Magnetic
• Trip Function Code: LI
• Trip Function: Long-Time, Instantaneous
• Trip Adjustability: Fixed Thermal, Fixed Magnetic
• Wire Gauge: 14 AWG - 1/0 AWG (Cu/Al)
• Max Wire: 1/0 AWG
• Min Wire: 14 AWG
• Available Options: Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, Handle Lock, Line and Load Lugs
• Accessories: Load Side Lugs
• Standards: CSA C22.2 No. 5, NEMA AB-1, UL 489
• Temp Rating: 40C
• Construction Features: HACR Rated, Reverse Feed, Non-Interchangeable Trip
• Manufacturer: Eaton Cutler-Hammer
• Family: Series C
• Amp: 15
• Volt: 600
• Category: Molded Case
• Connection: Feed-Thru
• Functions: LI - Long-Time and Instantaneous
• Protection: Thermal Magnetic
• AIC Ratings: 14kA@480V
• Frame Type: F Frame
• Dimensions (HxWxD): 6" x 4.13" x 3.38"
• MPN: FDB3015
• Country of Origin: United States
• Mounting: Panel
• Volts DC: 250
• Amps: 15
• Volts AC: 600
