Eaton FD3125L Eaton Electrical FD3125L Series C F Frame Molded Case Circuit Breaker Power 125A (Each)

Product Description

The Eaton FD3125L is a series C molded case circuit breaker designed for panelboards, switchboards, and busway applications. It features a fixed thermal and fixed magnetic trip type with a three-pole configuration rated for 125 amps. This circuit breaker operates at a voltage of up to 600 Vac or 250 Vdc and has an interrupt rating of 65 kAIC at 240 Vac and 35 kAIC at 480 Vac. It is suitable for various industrial and commercial applications, providing reliable protection for electrical systems.

• Rated for 125 amps and up to 600 Vac.
• Three-pole configuration for effective circuit protection.
• UL listed to meet North American electrical safety standards.

Product Highlights

Utilizes a fixed thermal and magnetic trip type for reliable circuit interruption.

Product Information

Standard Information

• Brand: Eaton
• MPN: FD3125L

Technical Specifications

• Catalog Number: FD3125L
• Voltage Rating: 600 Vac, 250 Vdc
• Current Rating: 125 Amps
• Number of Poles: 3
• Interrupt Rating: 65 kAIC at 240 Vac, 35 kAIC at 480 Vac
• Frequency Rating: 50/60 Hz
• Frame Type: F-frame
• Dimensions: 3.38 x 4.13 x 4.13 inches
• Weight: 4.5 lbs
