Eaton FD3125 C Series Type FD Molded Case Circuit Breaker 600 VAC/250 VDC 125 A

Product Description

The Eaton FD3125 C Series Molded Case Circuit Breaker has a voltage rating of six hundred volts alternating current and two hundred fifty volts direct current. It is designed for a maximum current of one hundred twenty-five amps and features three poles. This circuit breaker is suitable for use in a variety of applications, including panelboards, switchboards, and motor control centers.

• Voltage Rating: 600 VAC and 250 VDC
• Amperage Rating: 125 A
• Interrupt Rating: 65 kAIC at 240 VAC / 35 kAIC at 480 VAC

Product Highlights

This product is built for reliability in demanding environments and adheres to industry standards for safety and performance.

Product Information

Standard Information

• Brand: Eaton
• Category: Molded Case Circuit Breakers

Technical Specifications

• Type: Type FD
• Frame: F
• Phase: Three phases
• Trip Type: Fixed Thermal / Fixed Magnetic
• Wire Size: 4 to 4/0 AWG
• Dimensions: 3.38 x 4.13 x 4.13 inches
• Temperature Rating: 40 degrees Celsius
• Enclosure Type: NEMA AB1-1993
