EATON FD3100 C Series Type FD Molded Case Circuit Breaker 600 VAC/250 VDC 100 A 35 kAIC at 480 VAC/65 kAIC at 240 VAC

Product Description

The EATON FD3100 is a C Series Type FD Molded Case Circuit Breaker with a voltage rating of six hundred volts alternating current and two hundred fifty volts direct current. This product is designed for use in panelboards, switchboards, motor control centers, and busway applications, providing reliable circuit protection. With a current rating of one hundred amps, the FD3100 meets various electrical standards.

• Suitable for panelboard, switchboard, and motor control center applications
• Interruption ratings of thirty-five kAIC at four hundred eighty volts and sixty-five kAIC at two hundred forty volts
• Fixed thermal and fixed magnetic trip type for dependable operation

Product Highlights

This circuit breaker is renowned for its user acceptance and compliance with North American standards. Installation is simple, and it is tested for frequent use in various electrical assemblies.

Product Information

Standard Information

• Manufacturer: EATON
• Type: Molded Case Circuit Breaker

Technical Specifications

• Voltage Rating: 600 VAC/250 VDC
• Amperage Rating: 100 A
• Number of Poles: 3
• Trip Type: Fixed Thermal/Fixed Magnetic
• Interrupt Rating: 35 kAIC at 480 VAC, 65 kAIC at 240 VAC
• Frame: F
• Dimensions: 3.38 x 4.13 x 6 inches
• Temperature Rating: 40 degrees Celsius
